Liquidity, a high-level language for Tezos

Ressources

Contract Format

All the contracts have the following form:

let contract
      (parameter : TYPE)
      (storage : TYPE)
      (return : TYPE) =
      BODY

where TYPE is a type and BODY is the code of the contract, using the two arguments parameter and storage. The return variable cannot be used, it is special form to declare the return type of the contract. The parameter is the argument provided by the caller, and storage is the initial state of the contract.

A contract always returns a pair (return, storage), where return is the return value to the caller, and storage is the final state of the contract after the call.

Calling another contract

Calling another contract is done by using the following form:

let (RESULT, storage) = Contract.call CONTRACT AMOUNT STORAGE ARG
in
BODY

where:

All variables are destroyed during the call, so any state that should survive the call should be stored in the storage of the calling contract.

Operators and functions

Here is a list of equivalences between MICHELSON instructions and Liquidity functions:

Comparisons:

On data structures:

Operations:

Tuples

Tuples in Liquidity are compiled to pairs in Michelson:

x * y * z <=> pair x (pair y z)

Tuples can be accessed using the field access notation of Liquidity:

let t = (x,y,z) in
let should_be_true = t.(2) = z in
...

A new tuple can be created from another one using the field access update notation of Liquidity:

let t = (1,2,3) in
let z = t.(2) <- 4 in
...

Records

Record types can be declared and used inside a liquidity contract:

type storage = {
  x : string;
  y : int;
}

Such types can be created and used inside programs:

let r = { x = "foo"; y = 3 } in
r.x

Records are compiled as tuples.

Deep record creation is possible using the notation:

let r1 = { x = 1; y = { z = 3 } } in
let r2 = r1.y.z <- 4 in
...

Variants

Variants should be defined before use, before the contract declaration:

type t =
| X
| Y of int
| Z of string * nat

Variants can be created using:

let x = X 3 in
let y = Z s in
...

The match construct can be used to pattern-match on them, but only on the first constructor:

match x with
| X -> ...
| Y i -> ...
| Z s -> ...

where i and s are variables that are bound by the construct to the parameter of the variant.

A special case of variants is the Left | Right predefined variant, called variant:

type (`left, `right) variant =
| Left of `left
| Right of `right

All occurrences of these variants should be constrained with type annotations:

let x = (Left 3 : (int, string) variant) in
match x with
| Left left  -> ...
| Right right -> ...

Another special variant is the Source variant: it is used to refer to the contract that called the current contract.

let s = ( Source : (unit, unit) contract ) in
...

As for Left and Right, Source occurrences should be constrained by type annotations.

Functions

As for Michelson, functions in Liquidity are not closures. They can only access their only argument. The argument must be annotated with its (monomorphic) type.

Function applications are done using the Lambda.pipe function or the |> operator:

let succ = fun (x : int) -> x + 1 in
let one = 0 |> succ in
...

Loops

Loops in liquidity share some syntax with functions, but the body of the loop is not a function, so it can access the environment, as would a closure do:

let end_loop = 5 in
let x = Loop.loop (fun x ->
  ...
  ( x < end_loop, x')
  ) x_init
in
...

As shown in this example, the body of the loop returns a pair, whose first part is the condition to remain in the loop, and the second part is the accumulator.
